← Design LibraryResidential

Condo living and dining room

TV feature wall: fluted timber panel, low media console with lit plinth, and open display shelving niche

Build this look — one optionFLYHOME

FLYHOME is one way to build this look. The cabinetry pictured is an ELS concept, not a FLYHOME product.

Available for this look where P6 construction is technically appropriate — ELS specifies the platform by room and moisture zone.

See FLYHOME options at ALUMAX

4 references · concept studies, not photographs of completed projects

Browse our published examples freely. Matching references to your property, adapting layouts or finishes, and developing drawings begins within a paid ELS service.

condo living and dining room — concept study
Condo living and dining room
Concept study
condo living and dining room — concept study
Condo living and dining room
Concept study
condo living and dining room — concept study
Condo living and dining room
Concept study
condo living and dining room — concept study
Condo living and dining room
Concept study

Decisions behind this room

Before you choose a look for your condo living and dining room, these are the decisions that actually shape it — each shown with its options side by side, so the difference is visible rather than described.

LIV-08

Floor finish

Floor finish — SPC (stone-plastic composite)
SPC (stone-plastic composite)
Best for
Rooms that need timber's look with real moisture tolerance.
Watch out
The wear layer is thin: deep scratches cannot be sanded out, only replaced. A poorly levelled slab telegraphs through.
Floor finish — Porcelain tile
Porcelain tile
Best for
Wet and high-traffic areas.
Watch out
Hard and cold underfoot, and grout is the maintenance line — colour choice matters more than most clients expect.
Floor finish — Engineered timber
Engineered timber
Best for
Bedrooms and upper floors where warmth matters and water exposure is genuinely low.
Watch out
Real timber moves with humidity; in an unconditioned Sarawak room expect movement at the joints. Not for a ground floor with flood risk.

Supply and installation confirmed with your specification.

LIV-02

Air-conditioning

Air-conditioning — Ceiling cassette
Ceiling cassette
Best for
Even distribution across a square room from a single central point.
Watch out
Needs real ceiling void; it commits the ceiling design and is disruptive to retrofit.
Air-conditioning — Concealed ducted / zoned
Concealed ducted / zoned
Best for
Concealing the system entirely across several rooms from one plant location.
Watch out
The most demanding of the three: duct routing, void depth and return-air paths all have to work, and service access must be planned.
Air-conditioning — Wall split unit
Wall split unit
Best for
The pragmatic default — simplest to install, service and replace.
Watch out
The wall unit is visible and dictates where furniture can sit; it dates the room faster than the joinery.

Supply and installation confirmed with your specification.

LIV-07

Feature shelving

Feature shelving — Deep
Deep
Best for
Storing real objects — books, boxes, equipment — rather than styling pieces.
Watch out
Deep shelves throw a shadow and read heavy; the back becomes dead storage.
Feature shelving — Feature
Feature
Best for
Where the shelving is the composition, not just storage.
Watch out
It must be styled to work, which is a commitment the client has to want.
Feature shelving — Slim
Slim
Best for
A light visual line where the shelf holds a few pieces.
Watch out
It will not take books or heavy objects — be honest about intended use.

Supply and installation confirmed with your specification.

LIV-03

TV wall composition

TV wall composition — Console
Console
Best for
The simplest answer — a low unit that can be replaced.
Watch out
Cables are visible unless managed, and the wall above stays unresolved.
TV wall composition — Console panel
Console panel
Best for
Anchoring the TV to a panel while keeping the storage low and light.
Watch out
The panel width has to relate to the TV and the room, or it reads accidental.
TV wall composition — Full wall
Full wall
Best for
Making the whole wall one designed element with everything concealed.
Watch out
It commits the wall — a later TV size change or a moved socket is joinery work.

Supply and installation confirmed with your specification.

LIV-09

Paint system & sheen

Paint system & sheen — Acrylic matte
Acrylic matte
Best for
Walls where a flat, non-reflective surface hides minor unevenness.
Watch out
The least scrubbable — marks in a circulation zone will show and touch-up flashes.
Paint system & sheen — Mineral limewash
Mineral limewash
Best for
A soft, breathable finish with visible depth and movement.
Watch out
It is a texture, not just a colour — application skill decides the result, and touch-up is difficult.
Paint system & sheen — Satin acrylic
Satin acrylic
Best for
A durable, wipeable general-purpose finish for busy rooms.
Watch out
The sheen shows wall unevenness that a matte finish would hide.
Paint system & sheen — Semi-gloss enamel
Semi-gloss enamel
Best for
Trim, doors and anywhere that takes hands and cleaning.
Watch out
Unforgiving of surface defects and brush marks; the higher the sheen, the more it shows.
Paint system & sheen — Washable eggshell
Washable eggshell
Best for
The pragmatic middle for family rooms — cleanable without a shine.
Watch out
Not fully scrubbable despite the name; check the manufacturer's actual claim.

Supply and installation confirmed with your specification.

LIV-10

Visible acoustic treatment

Visible acoustic treatment — Fabric panels
Fabric panels
Best for
The most absorption per area — rooms with a real echo problem.
Watch out
Fabric collects dust and, in a humid room, needs to be a material that tolerates it.
Visible acoustic treatment — PET felt
PET felt
Best for
A durable, wipeable absorber that can also be a graphic element.
Watch out
Absorbs a narrower range than fabric over a cavity — good for speech, less for low frequencies.

Supply and installation confirmed with your specification.

LIV-04

Lighting levels — Muji Japandi

Lighting levels — Muji Japandi — Bespoke
Bespoke
Best for
Where lighting is doing real work — highlighting material, texture and joinery.
Watch out
The most coordination with ceiling and joinery; a late change is disruptive.
Lighting levels — Muji Japandi — Essential
Essential
Best for
A calm, even wash consistent with the style's restraint.
Watch out
One layer only — no accent, so the room reads flat after dark.
Lighting levels — Muji Japandi — Signature
Signature
Best for
Adding a second layer so the room changes between day and evening.
Watch out
More circuits means more switching; the control plan has to stay simple or the room is annoying to use.

Supply and installation confirmed with your specification.

LIV-05

Lighting levels — Cream Luxury

Lighting levels — Cream Luxury — Bespoke
Bespoke
Best for
Lighting that models the material — the point of this style.
Watch out
The most coordination with ceiling and joinery; late changes are disruptive.
Lighting levels — Cream Luxury — Essential
Essential
Best for
A warm, even base consistent with the style's softness.
Watch out
A single layer flattens the material depth this style depends on.
Lighting levels — Cream Luxury — Signature
Signature
Best for
A second layer so the finishes read after dark as well as by day.
Watch out
More circuits, more switching — keep the control plan legible.

Supply and installation confirmed with your specification.

LIV-06

Lighting levels — Simple Modern Minimalist

Lighting levels — Simple Modern Minimalist — Bespoke
Bespoke
Best for
Concealed and integrated light.
Watch out
Integration means joinery and ceiling coordination, and no room for a late move.
Lighting levels — Simple Modern Minimalist — Essential
Essential
Best for
Clean, even light that suits a minimal room.
Watch out
One layer leaves a minimal room feeling stark after dark.
Lighting levels — Simple Modern Minimalist — Signature
Signature
Best for
A second layer to give a spare room some depth in the evening.
Watch out
Fittings are visible in a minimal room — the fitting choice is part of the design.

Supply and installation confirmed with your specification.

LIV-01

Design language

Design language — Cream Luxury
Cream Luxury
Best for
Clients who want warmth and softness with a sense of occasion.
Watch out
Pale, warm finishes show marks and need more upkeep in a family home.
Design language — Muji Japandi
Muji Japandi
Best for
Calm, uncluttered rooms where material and daylight do the work.
Watch out
Restraint only reads as calm when the storage is genuinely sufficient — otherwise it reads bare.
Design language — Scandinavian
Scandinavian
Best for
Light, practical rooms with a soft palette and honest materials.
Watch out
Very pale timber and textiles can feel cool against Sarawak's light; the tone needs testing on site.
Design language — Simple Modern Minimalist
Simple Modern Minimalist
Best for
Clean lines and quiet surfaces where the architecture leads.
Watch out
Minimalism is unforgiving of tolerance — every junction and gap shows.
Design language — Warm Wood Modern
Warm Wood Modern
Best for
Warmth and grain as the main event, with modern lines.
Watch out
Timber tone must be consistent across suppliers and rooms or the property reads mismatched.

Supply and installation confirmed with your specification.

Concept renders — a design render, not a photo. Shown as design options for one decision.
